sbp209
Max Lifting Weight (SWL) 990kg
Max Radius 6.5m
Max Height 7.5m
Crane Width 770mm
spx312
Max Lifting Weight (SWL) 1200kg
Max Radius 9.6m
Max Height 10.7m
Crane Width 770mm
spx424
Max Lifting Weight (SWL) 2400kg
Max Radius 11.9m
Max Height 15m
Crane Width 780mm
spx527
Max Lifting Weight (SWL) 2700kg
Max Radius 11.2m
Max Height 18.3m
Crane Width 1100mm
spx1040
Max Lifting Weight (SWL) 4000kg
Max Radius 14.6m
Max Height 23.5m
Crane Width 1400mm
spx1275
Max Lifting Weight (SWL) 7500kg
Max Radius 20m
Max Height 26m
Crane Width 1450mm
Key features
- Light & versatile
- 280° rotation
- Extendable tracks 45°
- Boom pressure indicator
- Stability control system
- Crane carrier interlock
- Two speed tracks
- LED working light
- Tower lamp
- Electric pack
- Automatic choke
- 2 ton – 1 sheave pulley block
- Offset runner jib
- Extendable tracks
- Low marking white tracks
- Visual angle indicator
- Outrigger mats and tray
- Personalized crane colour
- Warm up kit
| Column title | Column title |
|---|---|
| Crane capacity | 990kg |
| Max working radius | 6.5m |
| Max lifting height | 7.5m |
| Rope length (max) | 53m |
| Dimensions (folded) | 2500(l) x 770(w) x 1600(h)mm |
| Weight (unladen) | 1450kg |
| Point loadings | Due to the many variables involved, point loadings are only available on request |
